Desciption

Model

Parameters

MCDR-200V

MCDR-320V

Power

20kW (can take clear images for the body no more than 35cm

thickness )

32kW (can take clear images for the body no more than 50cm

thickness )

Power supply

Single-phase 220V 50/60HZ

(wire diameter>4mm², internal resistance<0.5Ω)

mA		10~320 mA	10~400 mA
mAS		1~320Mas, stepping by R’10	1~400mAS, stepping by R’10
KV		40~125kV, stepping by 1kV
Exposure time		0.003~6.3S adjustment: Increased /reduced by 1mS each time
X-ray tube		Toshiba 7239/7242, Toshiba 7239/7242, or Chinese brands are available for options
Anode rotating speed/Anode heat capacity		2800prm/140kHU
Generator frequency		400kHz
Radiography table(W*L cm)		Width: 70cm, length: 140/120cm (either) urinary trough can be equipped with
Flat panel detector	Imaging area	1717 inches (or 1417 inches)
	Pixel size	140um
	A/D conversion	16bits
	Spatial resolution	3.6lp/mm
Software		Professional veterinary software
Computer configuration		Intel i5 processor; 8G memory, 2G discrete graphics card, 128G solid state drive + 1TB mechanical hard drive, PCI-E and Ethernet dual Gigabit network cable interface, R232 interface; 22.5-inch Dell professional small dot pitch monitor; operating system: win10

MCDR-200V/MCDR-320V Drawings

The size of the machine is as below (mm):

Customizable Options

The table length can be 1.2 m or 1.4m;
The urinary trough of the table is optional according toneeds
The 4 corners of the table is optional(angleR5-50)
The logo of the table can be customized with stainless steel stickers or screen printing; the stickers can be beautified and pasted by customers
Movable casters areoptional;
