No. |
Item |
Specification |
One |
Equipment Introduction |
|
1 |
Use |
For all parts of the body MRI Scan |
Two |
Magnet System |
|
1 |
magnetic field Strength |
3.0T |
2 |
Center frequency |
127.7MHz |
3 |
Magnet Type |
Superconducting Magnet |
4 |
Magnet Material |
Niobium-titanium alloys |
5 |
Anti-electromagnetic interference |
Yes |
6 |
Magnet stability |
0.1 ppm/h |
7 |
Uniformity of magnetic field |
Typical values, V-RMS measurements |
7.1 |
10cm DSV |
0.005ppm |
7.2 |
20cm DSV |
0.027ppm |
7.3 |
30cm DSV |
0.056ppm |
7.4 |
40cm DSV |
0.250ppm |
7.5 |
45cm DSV |
0.460ppm |
7.6 |
50cm DSV |
1.500ppm |
8 |
Compensation technology of magnetic field shimming |
Yes |
9 |
Shim mode |
Active uniform field + passive leveling |
10 |
Magnet weight (with liquid helium) |
4600kg |
11 |
Magnet length (excluding shell) |
160cm |
12 |
Patient aperture. |
60cm |
13 |
Cooling mode |
Liquid helium |
14 |
Liquid helium consumption rate |
0 |
15 |
Volume of liquid helium |
1450L |
16 |
Cold head Type |
4K Cold Head |
17 |
5 Gauss line range |
3.1m x 3.1m x 5.5m |
Three |
Gradient System |
1 |
Gradient Control Technology |
Full digital real Time |
2 |
Gradient Cooling Mode |
Water |
3 |
Maximum gradient intensity |
46mT/m |
4 |
Maximal gradient slew rate |
288T/m/s |
5 |
Minimum gradient rise time |
0.159ms |
6 |
Maximum gradient field, maximum gradient switching rate and maximum FOV can be achieved simultaneously |
Yes |
7 |
Max duty ratio |
100% |
8 |
Shielding mode |
Active shielding |
9 |
Gradient working mode |
Non-resonant type |
10 |
Gradient Noise Reduction Technology |
Yes |
Four |
RF System |
|
1 |
Number of independent RF sources |
1 or 2 |
2 |
Number of independent RF amplifiers |
1 or 2 |
3 |
Each RF source can independently adjust the RF pulse phase, waveform, amplitude |
Yes |
4 |
RF Transmitter Power |
35kW or 18kW * 2 |
5 |
Max RF transmit field |
20μT |
6 |
RF Power Amplifier Type |
Water-cooled / Digital Interface |
7 |
Transmitter Coil auto tuning |
Yes |
8 |
Number of independent RF channels |
16 / 32 |
9 |
RF Receiver Sampling rate |
100MHz |
10 |
Receive dynamic range (1Hz bandwidth) |
140db |
11 |
Noise coefficient |
0.5dB |
12 |
Full digital demodulation and filtering technology |
Yes |
13 |
RF Energy Monitoring |
|
13.1 |
Real-time digital RF energy Monitoring |
Yes |
13.2 |
Real-time digital RF energy accumulation monitoring |
Yes |
13.3 |
Real-time digital RF energy |
Yes |
accumulation monitoring |
|
|
14 |
RF receiver coils and related technologies |
|
14.1 |
Orthogonal transmitting / receiving |
Yes |
14.2 |
Head-neck coils |
24 Channel |
14.3 |
Body Coil |
12 Channel |
14.4 |
Spine Coil |
18 Channel |
14.5 |
Large Flexible Multi-function coil |
8 Channel |
14.6 |
Breast Dedicated coil |
8 Channel |
14.7 |
Knee Dedicated coil |
8 Channel |
14.8 |
Shoulder Dedicated coil |
Optional |
14.9 |
Ankle Dedicated coil |
Optional |
14.10 |
AIT Scanning technology |
Yes |
14.11 |
Note: coil configuration is subject to the final contract |
|
Five |
Computer |
|
1 |
CPU |
3.4GHz |
2 |
Number of processor digits |
64bit |
3 |
Memory capacity |
8GB |
4 |
Hard disk capacity |
500GB |
5 |
Image storage capacity (512 matrix) |
0.6million |
6 |
Display resolution |
1920 x 1200 |
7 |
Display size and specifications |
24 inch |
8 |
Maximum acquisition matrix |
1024 x 1024 |
9 |
Maximum Reconstruction matrix |
1024 x 1024 |
Six |
Post-processing interface |
|
1 |
Software Control camera Technology |
Yes |
2 |
DICOM 3.0 interfaces and PACS network connections (including print, transmit, receive, query , worklist, MPPs ) |
Yes |
3 |
Standard Laser Camera Digital interface |
Yes |
Seven |
Scan parameters |
|
1 |
X axis Max FOV |
500mm |
2 |
Y axis Max FOV |
500mm |
3 |
Z axis Max FOV |
500mm |
4 |
Minimum FOV |
5mm |
5 |
Thinnest layer thickness |
0.1mm |
6 |
2D SE Shortest sequence TR time (128 matrix) |
7ms |
7 |
2D SE Shortest sequence TE time (128 matrix) |
2.4ms |
8 |
2D FSE Shortest sequence TR time (128 matrix) |
7ms |
9 |
2D FSE Shortest sequence TE time (128 matrix) |
2.4ms |
10 |
2D FSE Sequence minimum echo spacing (128 matrix) |
2.4ms |
11 |
2D FSE sequence maximum echo chain length (ETL) |
512 |
12 |
2D GRE Shortest sequence TR time (128 matrix) |
1.0ms |
13 |
2D GRE Shortest sequence TE time (128 matrix) |
0.6ms |
14 |
3D GRE Shortest sequence TR time (128 matrix) |
1.2ms |
15 |
3D GRE Shortest sequence TE time (128 matrix) |
0.5ms |
16 |
EPI Sequence minimum echo interval (128 matrix) |
0.57ms |
17 |
EPI Shortest sequence TR time (128 matrix) |
4.7ms |
18 |
EPI Shortest sequence TE time (128 matrix) |
1.3ms |
19 |
Maximum dispersion weighted b value |
10000 |
Eight |
Scanning technology and sequence |
1 |
Spin echo sequence (FSE) |
Yes |
1.1 |
2d/3d Fast spin echo |
Yes |
1.2 |
SE sequences measured by tissue relaxation time |
Yes |
1.3 |
SE sequences with selectable angles |
Yes |
1.4 |
Single echo, dual echo and multi-echo technology |
Yes |
1.5 |
Single excitation fast spin echo sequence |
Yes |
1.6 |
Fat-sat sequence |
Yes |
1.7 |
Fast Fat saturation Technology |
Yes |
1.8 |
Water-sat sequence |
Yes |
1.9 |
Reverse recovery (IR) |
Yes |
1.10 |
General IR sequence |
Yes |
1.11 |
FLAIR |
Yes |
1.12 |
Fast T1-FLAIR |
Yes |
1.13 |
Fast T2-FLAIR |
Yes |
1.14 |
Rapid inversion recovery sequence (fat-sat, water-sat) |
Yes |
1.15 |
Short TI inverse echo water-fat separation imaging |
Yes |
1.16 |
“True” inversion recovery sequence (contrast imaging of gray-white matter) |
Yes |
2 |
Gradient echo (2d/3d), including |
Yes |
2.1 |
Multi-layer gradient echo |
Yes |
2.2 |
2d/3d residual magnetization removal gradient echo technology |
Yes |
2.3 |
2d/3d residual magnetization gradient echo technology |
Yes |
2.4 |
Heavy T2 weighted High Contrast sequence |
Yes |
2.5 |
3D Gradient Echo Technology |
Yes |
2.6 |
Fast steady-state progressive gradient Echo |
Yes |
2.7 |
Super-fast field echo sequence |
Yes |
2.8 |
Three-dimensional imaging technology |
Yes |
3 |
Planar echo imaging (EPI) |
Yes |
3.1 |
Single-excitation planar echo imaging technology |
Yes |
3.2 |
Multi-excitation planar echo imaging |
Yes |
3.3 |
Spin echo EPI |
Yes |
3.4 |
Gradient echo EPI |
Yes |
3.5 |
Reverse EPI |
Yes |
3.6 |
High resolution EPI Collection |
Yes |
4 |
Neuroimaging technology |
Yes |
4.1 |
High resolution anatomical imaging |
Yes |
4.2 |
High resolution three-dimensional imaging technology of inner ear |
Yes |
4.3 |
Full Spinal cord imaging |
Yes |
5 |
Diffusion imaging technology |
Yes |
5.1 |
ADC Imaging |
Yes |
5.2 |
Isotropic acquisition |
Yes |
5.3 |
Anisotropic acquisition |
Yes |
5.4 |
ADC Value Measurement |
Yes |
5.5 |
ADC-map |
Yes |
5.6 |
Automatic acquisition and processing |
Yes |
5.7 |
Single-shot EPI |
Yes |
5.8 |
Multi-shots EPI |
Yes |
5.9 |
Real-time diffusion imaging |
Yes |
5.10 |
Automatically generate ADC diagram |
Yes |
5.11 |
Optional optimization B value |
Yes |
6 |
Vascular imaging technology |
Yes |
6.1 |
Time Of Fly Technology (2d/3d) |
Yes |
6.2 |
Imaging technology of arteriovenous separation |
Yes |
6.3 |
MTC technology |
Yes |
6.4 |
Maximum density projection technology |
Yes |
6.5 |
Variable reversal Angle RF technology |
Yes |
6.6 |
MIP |
Yes |
6.7 |
2d/3d Water Imaging Technology (MRCP, MRU) |
Yes |
6.8 |
Real-time interactive MIP |
Yes |
7 |
Artifact removal technology |
Yes |
7.1 |
Fluid compensation |
Yes |
7.2 |
Respiratory compensation |
Yes |
7.3 |
Flow correction |
Yes |
7.4 |
Regional saturation Technology |
Yes |
7.5 |
Deconvolution Artifact Removal technology |
Yes |
7.6 |
Motion Artifact Elimination technology |
Yes |
7.7 |
Image filtering Enhancement technology |
Yes |
7.8 |
K Space Noise Reduction technology |
Yes |
7.9 |
Ring artifact suppression |
Yes |
8 |
Section-scan technology |
Yes |
8.1 |
Semi-scanning technology |
Yes |
8.2 |
Full directional partial coding acquisition technology |
Yes |
8.3 |
Rectangular FOV acquisition technology |
Yes |
8.4 |
Three-dimensional overlapping continuous acquisition technology |
Yes |
8.5 |
Parallel acquisition and reconstruction technology |
Yes |
8.6 |
Partial echo Acquisition |
Yes |
9 |
Other imaging technology |
Yes |
9.1 |
Short TR TE Fast Imaging |
Yes |
9.2 |
Three-dimensional positioning system |
Yes |
9.3 |
Positioning technology of radial slice layer |
Yes |
9.4 |
Scan pause |
Yes |
9.5 |
Variable Bandwidth |
Yes |
technology |
|
|
9.6 |
Pre-scanning technology |
Yes |
9.7 |
Signal noise ratio display function |
Yes |
9.8 |
Mute Scanning technology |
Yes |
9.9 |
Real-time interactive imaging |
Yes |
9.10 |
Real-time localization |
Yes |
9.11 |
Real-Time Interactive parameter change |
Yes |
9.12 |
High Resolution imaging |
Yes |
9.13 |
Combined scan function |
Yes |
9.14 |
Water Saturation Technology |
Yes |
9.15 |
Pre-saturated technology |
Yes |
9.16 |
Maximum saturation zone number |
3 |
9.17 |
Parallel saturation Zone |
Yes |
9.18 |
Adjoin saturation Zone |
Yes |
9.19 |
Fat saturation Technology |
Yes |
9.20 |
Signal averaging technology |
Yes |
9.21 |
Frequency Coding Direction Extended acquisition |
Yes |
9.22 |
Phase coding direction expands acquisition |
Yes |
9.23 |
Partial Center scanning technology |
Yes |
9.24 |
Variable K space Filling method |
Yes |
9.25 |
K Fast Space Acquisition |
Yes |
9.26 |
Coil Sensitivity correction technology |
Yes |
9.27 |
Enhancement technology |
Yes |
9.28 |
Correction technology of image luminance uniformity |
Yes |
9.29 |
Automatic Center Scanning technology |
Yes |
9.30 |
Image reconstruction Technology |
Yes |
9.31 |
Image interpolation Amplification Technology |
Yes |
9.32 |
Image Distortion Correction Technology |
Yes |
10 |
Advanced clinical application packages |
Yes |
10.1 |
Neuro Imaging software Package |
Yes |
10.2 |
Body Imaging software Package |
Yes |
10.3 |
Bone and joint imaging software Package |
Yes |
10.4 |
Tumor Imaging software Package |
Yes |
10.5 |
Breast Imaging software Package |
Yes |
Nine |
The patient examine environment |
|
1 |
Two-way patient call system |
Yes |
2 |
Magnetic noise-reducing headphones |
Yes |
3 |
Aperture Ventilation system |
Yes |
4 |
Aperture lighting system |
Yes |
5 |
Embedded display |
Yes |
5.1 |
Patient monitoring System |
Yes |
5.2 |
Bedside Patient Control system |
Yes |
6 |
Patient Emergency call Device |
Yes |
7 |
Maximum load bearing of inspection bed |
200KG |
8 |
Minimum bed height for inspection beds |
62cm |
9 |
Maximum speed of horizontal motion of scan bed |
20cm/s |
10 |
Scan bed Length |
245cm |
11 |
Maximum scanning range |
>150cm |
12 |
Multi-station stitching |
Yes |
13 |
Bedside Emergency brake button |
Yes |
14 |
Bedside Switch |
Yes |
15 |
Breath gating |
Yes |
